Honeywell's JetWave is a piece of satellite communications hardware produced by Honeywell that enables global in-flight internet connectivity. Its connectivity is provided using Inmarsat’s GX Aviation network. The JetWave platform is used in business and general aviation, as well as defense and commercial airline users. == History == In 2012, Honeywell announced it would provide Inmarsat with the hardware for its GX Ka-band in-flight connectivity network. The Ka-band (pronounced either "kay-ay band" or "ka band") is a portion of the microwave part of the electromagnetic spectrum defined as frequencies in the range 27.5 to 31 gigahertz (GHz). In satellite communications, the Ka-band allows higher bandwidth communication. In 2017, after five years and more than 180 flight hours and testing, JetWave was launched as part of GX Aviation with Lufthansa Group. Honeywell’s JetWave was the exclusive terminal hardware option for the Inmarsat GX Aviation network; however, the exclusivity clause in that contract has expired. In July 2019, the United States Air Force selected Honeywell’s JetWave satcom system for 70 of its C-17 Globemaster III cargo planes. In December 2019, it was reported that six AirAsia aircraft had been fitted with Inmarsat’s GX Aviation Ka-band connectivity system and is slated to be implemented fleetwide across AirAsia’s Airbus A320 and A330 models in 2020, requiring installation of JetWave atop AirAsia’s fuselages. Today, Honeywell’s JetWave hardware is installed on over 1,000 aircraft worldwide. In August 2021, the Civil Aviation Administration of China approved a validation of Honeywell’s MCS-8420 JetWave satellite connectivity system for Airbus 320 aircraft. In December 2021, Honeywell, SES, and Hughes Network Systems demonstrated multi-orbit high-speed airborne connectivity for military customers using Honeywell’s JetWave MCX terminal with a Hughes HM-series modem, and SES satellites in both medium Earth orbit (MEO) and geostationary orbit (GEO). The tests achieved full duplex data rates of more than 40 megabits per second via a number of SES' (GEO) satellites including GovSat-1, and the high-throughput, low-latency O3b MEO satellite constellation, with connections moving between GEO/MEO links in under 30 sec. == Uses == === Commercial aviation === Honeywell’s JetWave enables air transport and regional aircraft to connect to Inmarsat’s GX Aviation network. The multichannel satellite (MSC) JetWave terminals share the same antenna controller, modem and router hardware with the business market, but have an MCS-8200 fuselage-mounted antenna. === Business aviation === Honeywell’s JetWave hardware allows users to connect to Inmarsat’s Jet ConneX, a business aviation broadband connectivity offering to provide Wi-Fi for connected devices. JetWave offers a tail-mount antenna for business jets. === Defense === Honeywell’s JetWave satellite communications system for defense allows users to connect to the Inmarsat GX network, offering global coverage for military airborne operators, including over water, over nontraditional flight paths and in remote areas. JetWave and the Inmarsat GX network enable mission-critical applications like real-time weather; videoconferencing; large file transfers; encryption capabilities; in-flight briefings; intelligence, surveillance, and reconnaissance video; and secure communications. JetWave is configurable for a variety of military platforms and offers antennas for large and small airframes.
Jaggaer
JAGGAER, formerly SciQuest, is a provider of cloud-based business automation technology for Business Spend Management. Its headquarters is in Durham, North Carolina. == Company history == SciQuest was established in 1995 as a B2B eCommerce exchange.The company went public with an IPO in 1999. In 2001, SciQuest transitioned from a B2B exchange company into eProcurement software and supplier enablement platforms. SciQuest was taken private in 2004 and continued to move into eProcurement, inventory management and accounts payable automation. SciQuest completed an IPO in September 2010, raising approximately $57 million. SciQuest, and its 510 person workforce, was taken private in June 2016 as part of a $509 million acquisition by Accel-KKR, a private equity firm headquartered in Menlo Park, CA. In 2017 SciQuest was rebranded as JAGGAER and announced increased focus on offering a complete, integrated source-to-pay suite. Along with the name change, the company expanded its market focus to manufacturing, healthcare, consumer packaged goods, retail, education, life sciences, logistics and the public sector. JAGGAER acquired the European direct materials procurement specialist Pool4Tool in June 2017 giving it end-to-end direct as well as indirect materials procurement coverage. JAGGAER acquired spend management company BravoSolution in 2017, and entered into a joint venture with United Arab Emirates-based Tejari. In February 2019 JAGGAER launched JAGGAER One, which unifies its full product suite on a single platform. In 2019 the UK-based private equity firm Cinven acquired a majority holding in the company. Jim Bureau was subsequently named JAGGAER's Chief Executive Officer. Bureau left the firm in March 2023, and Andy Hovancik was announced as the company's CEO in June. In 2024, JAGGAER was acquired by Vista Equity Partners, a private equity firm specializing in enterprise software investments. == Current positioning == As of April 2025, JAGGAER positions itself as "an enterprise procurement and supplier collaboration SaaS provider." Its core technology platform, which is called JAGGAER One, serves "direct and indirect procurement with specializations in Higher Education, Discrete and Process Manufacturing, and Public Sector." == Product Categories == The JAGGAER One platform supports the following products: Spend Analytics Category Management Supplier Management Sourcing Contracts eProcurement Invoicing Inventory Management Supply Chain Collaboration Quality Management == Acquisitions == SciQuest acquired the following companies: AECsoft - January 2011. Provider of supplier management and sourcing technology. Upside Software, Inc. - August 2012. Provider of contract lifecycle management (CLM) solutions. Spend Radar, LLC - October 2012, Provider of spend analysis software. CombineNet - September 2013, Provider of advanced sourcing software JAGGAER acquired the following companies: POOL4TOOL - June 2017, Provider of direct sourcing and supply chain management software BravoSolution - December 2017, Provider of global platform spend management solutions
Random forest
Random forests or random decision forests is an ensemble learning method for classification, regression and other tasks that works by creating a multitude of decision trees during training. For classification tasks, the output of the random forest is the class selected by most trees. For regression tasks, the output is the average of the predictions of the trees. Random forests correct for decision trees' habit of overfitting to their training set. The first algorithm for random decision forests was created in 1995 by Tin Kam Ho using the random subspace method, which, in Ho's formulation, is a way to implement the "stochastic discrimination" approach to classification proposed by Eugene Kleinberg. An extension of the algorithm was developed by Leo Breiman and Adele Cutler, who registered "Random Forests" as a trademark in 2006 (as of 2019, owned by Minitab, Inc.). The extension combines Breiman's "bagging" idea and random selection of features, introduced first by Ho and later independently by Amit and Geman in order to construct a collection of decision trees with controlled variance. == History == The general method of random decision forests was first proposed by Salzberg and Heath in 1993, with a method that used a randomized decision tree algorithm to create multiple trees and then combine them using majority voting. This idea was developed further by Ho in 1995. Ho established that forests of trees splitting with oblique hyperplanes can gain accuracy as they grow without suffering from overtraining, as long as the forests are randomly restricted to be sensitive to only selected feature dimensions. A subsequent work along the same lines concluded that other splitting methods behave similarly, as long as they are randomly forced to be insensitive to some feature dimensions. This observation that a more complex classifier (a larger forest) gets more accurate nearly monotonically is in sharp contrast to the common belief that the complexity of a classifier can only grow to a certain level of accuracy before being hurt by overfitting. The explanation of the forest method's resistance to overtraining can be found in Kleinberg's theory of stochastic discrimination. The early development of Breiman's notion of random forests was influenced by the work of Amit and Geman who introduced the idea of searching over a random subset of the available decisions when splitting a node, in the context of growing a single tree. The idea of random subspace selection from Ho was also influential in the design of random forests. This method grows a forest of trees, and introduces variation among the trees by projecting the training data into a randomly chosen subspace before fitting each tree or each node. Finally, the idea of randomized node optimization, where the decision at each node is selected by a randomized procedure, rather than a deterministic optimization was first introduced by Thomas G. Dietterich. The proper introduction of random forests was made in a paper by Leo Breiman, that has become one of the world's most cited papers. This paper describes a method of building a forest of uncorrelated trees using a CART like procedure, combined with randomized node optimization and bagging. In addition, this paper combines several ingredients, some previously known and some novel, which form the basis of the modern practice of random forests, in particular: Using out-of-bag error as an estimate of the generalization error. Measuring variable importance through permutation. The report also offers the first theoretical result for random forests in the form of a bound on the generalization error which depends on the strength of the trees in the forest and their correlation. == Algorithm == === Preliminaries: decision tree learning === Decision trees are a popular method for various machine learning tasks. Tree learning is almost "an off-the-shelf procedure for data mining", say Hastie et al., "because it is invariant under scaling and various other transformations of feature values, is robust to inclusion of irrelevant features, and produces inspectable models. However, they are seldom accurate". In particular, trees that are grown very deep tend to learn highly irregular patterns: they overfit their training sets, i.e. have low bias, but very high variance. Random forests are a way of averaging multiple deep decision trees, trained on different parts of the same training set, with the goal of reducing the variance. This comes at the expense of a small increase in the bias and some loss of interpretability, but generally greatly boosts the performance in the final model. === Bagging === The training algorithm for random forests applies the general technique of bootstrap aggregating, or bagging, to tree learners. Given a training set X = x1, ..., xn with responses Y = y1, ..., yn, bagging repeatedly (B times) selects a random sample with replacement of the training set and fits trees to these samples: After training, predictions for unseen samples x' can be made by averaging the predictions from all the individual regression trees on x': f ^ = 1 B ∑ b = 1 B f b ( x ′ ) {\displaystyle {\hat {f}}={\frac {1}{B}}\sum _{b=1}^{B}f_{b}(x')} or by taking the plurality vote in the case of classification trees. This bootstrapping procedure leads to better model performance because it decreases the variance of the model, without increasing the bias. This means that while the predictions of a single tree are highly sensitive to noise in its training set, the average of many trees is not, as long as the trees are not correlated. Simply training many trees on a single training set would give strongly correlated trees (or even the same tree many times, if the training algorithm is deterministic); bootstrap sampling is a way of de-correlating the trees by showing them different training sets. Additionally, an estimate of the uncertainty of the prediction can be made as the standard deviation of the predictions from all the individual regression trees on x′: σ = ∑ b = 1 B ( f b ( x ′ ) − f ^ ) 2 B − 1 . {\displaystyle \sigma ={\sqrt {\frac {\sum _{b=1}^{B}(f_{b}(x')-{\hat {f}})^{2}}{B-1}}}.} The number B of samples (equivalently, of trees) is a free parameter. Typically, a few hundred to several thousand trees are used, depending on the size and nature of the training set. B can be optimized using cross-validation, or by observing the out-of-bag error: the mean prediction error on each training sample xi, using only the trees that did not have xi in their bootstrap sample. The training and test error tend to level off after some number of trees have been fit. === From bagging to random forests === The above procedure describes the original bagging algorithm for trees. Random forests also include another type of bagging scheme: they use a modified tree learning algorithm that selects, at each candidate split in the learning process, a random subset of the features. This process is sometimes called "feature bagging". The reason for doing this is the correlation of the trees in an ordinary bootstrap sample: if one or a few features are very strong predictors for the response variable (target output), these features will be selected in many of the B trees, causing them to become correlated. An analysis of how bagging and random subspace projection contribute to accuracy gains under different conditions is given by Ho. Typically, for a classification problem with p {\displaystyle p} features, p {\displaystyle {\sqrt {p}}} (rounded down) features are used in each split. For regression problems the inventors recommend p / 3 {\displaystyle p/3} (rounded down) with a minimum node size of 5 as the default. In practice, the best values for these parameters should be tuned on a case-to-case basis for every problem. === ExtraTrees === Adding one further step of randomization yields extremely randomized trees, or ExtraTrees. As with ordinary random forests, they are an ensemble of individual trees, but there are two main differences: (1) each tree is trained using the whole learning sample (rather than a bootstrap sample), and (2) the top-down splitting is randomized: for each feature under consideration, a number of random cut-points are selected, instead of computing the locally optimal cut-point (based on, e.g., information gain or the Gini impurity). The values are chosen from a uniform distribution within the feature's empirical range (in the tree's training set). Then, of all the randomly chosen splits, the split that yields the highest score is chosen to split the node. Similar to ordinary random forests, the number of randomly selected features to be considered at each node can be specified. Default values for this parameter are p {\displaystyle {\sqrt {p}}} for classification and p {\displaystyle p} for regression, where p {\displaystyle p} is the number of features in the model. === Random forests for high-dimensional data === The basic random forest procedure may
Correspondence analysis
Correspondence analysis (CA) is a multivariate statistical technique proposed by Herman Otto Hartley (Hirschfeld) and later developed by Jean-Paul Benzécri. It is conceptually similar to principal component analysis, but applies to categorical rather than continuous data. In a manner similar to principal component analysis, it provides a means of displaying or summarising a set of data in two-dimensional graphical form. Its aim is to display in a biplot any structure hidden in the multivariate setting of the data table. As such it is a technique from the field of multivariate ordination. Since the variant of CA described here can be applied either with a focus on the rows or on the columns it should in fact be called simple (symmetric) correspondence analysis. It is traditionally applied to the contingency table of a pair of nominal variables where each cell contains either a count or a zero value. If more than two categorical variables are to be summarized, a variant called multiple correspondence analysis should be chosen instead. CA may also be applied to binary data given the presence/absence coding represents simplified count data i.e. a 1 describes a positive count and 0 stands for a count of zero. Depending on the scores used CA preserves the chi-square distance between either the rows or the columns of the table. Because CA is a descriptive technique, it can be applied to tables regardless of a significant chi-squared test. Although the χ 2 {\displaystyle \chi ^{2}} statistic used in inferential statistics and the chi-square distance are computationally related they should not be confused since the latter works as a multivariate statistical distance measure in CA while the χ 2 {\displaystyle \chi ^{2}} statistic is in fact a scalar not a metric. == Details == Like principal components analysis, correspondence analysis creates orthogonal components (or axes) and, for each item in a table i.e. for each row, a set of scores (sometimes called factor scores, see Factor analysis). Correspondence analysis is performed on the data table, conceived as matrix C of size m × n where m is the number of rows and n is the number of columns. In the following mathematical description of the method capital letters in italics refer to a matrix while letters in italics refer to vectors. Understanding the following computations requires knowledge of matrix algebra. === Preprocessing === Before proceeding to the central computational step of the algorithm, the values in matrix C have to be transformed. First compute a set of weights for the columns and the rows (sometimes called masses), where row and column weights are given by the row and column vectors, respectively: w m = 1 n C C 1 , w n = 1 n C 1 T C . {\displaystyle w_{m}={\frac {1}{n_{C}}}C\mathbf {1} ,\quad w_{n}={\frac {1}{n_{C}}}\mathbf {1} ^{T}C.} Here n C = ∑ i = 1 n ∑ j = 1 m C i j {\displaystyle n_{C}=\sum _{i=1}^{n}\sum _{j=1}^{m}C_{ij}} is the sum of all cell values in matrix C, or short the sum of C, and 1 {\displaystyle \mathbf {1} } is a column vector of ones with the appropriate dimension. Put in simple words, w m {\displaystyle w_{m}} is just a vector whose elements are the row sums of C divided by the sum of C, and w n {\displaystyle w_{n}} is a vector whose elements are the column sums of C divided by the sum of C. The weights are transformed into diagonal matrices W m = diag ( 1 / w m ) {\displaystyle W_{m}=\operatorname {diag} (1/{\sqrt {w_{m}}})} and W n = diag ( 1 / w n ) {\displaystyle W_{n}=\operatorname {diag} (1/{\sqrt {w_{n}}})} where the diagonal elements of W n {\displaystyle W_{n}} are 1 / w n {\displaystyle 1/{\sqrt {w_{n}}}} and those of W m {\displaystyle W_{m}} are 1 / w m {\displaystyle 1/{\sqrt {w_{m}}}} respectively i.e. the vector elements are the inverses of the square roots of the masses. The off-diagonal elements are all 0. Next, compute matrix P {\displaystyle P} by dividing C {\displaystyle C} by its sum P = 1 n C C . {\displaystyle P={\frac {1}{n_{C}}}C.} In simple words, Matrix P {\displaystyle P} is just the data matrix (contingency table or binary table) transformed into portions i.e. each cell value is just the cell portion of the sum of the whole table. Finally, compute matrix S {\displaystyle S} , sometimes called the matrix of standardized residuals, by matrix multiplication as S = W m ( P − w m w n ) W n {\displaystyle S=W_{m}(P-w_{m}w_{n})W_{n}} Note, the vectors w m {\displaystyle w_{m}} and w n {\displaystyle w_{n}} are combined in an outer product resulting in a matrix of the same dimensions as P {\displaystyle P} . In words the formula reads: matrix outer ( w m , w n ) {\displaystyle \operatorname {outer} (w_{m},w_{n})} is subtracted from matrix P {\displaystyle P} and the resulting matrix is scaled (weighted) by the diagonal matrices W m {\displaystyle W_{m}} and W n {\displaystyle W_{n}} . Multiplying the resulting matrix by the diagonal matrices is equivalent to multiply the i-th row (or column) of it by the i-th element of the diagonal of W m {\displaystyle W_{m}} or W n {\displaystyle W_{n}} , respectively. === Interpretation of preprocessing === The vectors w m {\displaystyle w_{m}} and w n {\displaystyle w_{n}} are the row and column masses or the marginal probabilities for the rows and columns, respectively. Subtracting matrix outer ( w m , w n ) {\displaystyle \operatorname {outer} (w_{m},w_{n})} from matrix P {\displaystyle P} is the matrix algebra version of double centering the data. Multiplying this difference by the diagonal weighting matrices results in a matrix containing weighted deviations from the origin of a vector space. This origin is defined by matrix outer ( w m , w n ) {\displaystyle \operatorname {outer} (w_{m},w_{n})} . In fact matrix outer ( w m , w n ) {\displaystyle \operatorname {outer} (w_{m},w_{n})} is identical with the matrix of expected frequencies in the chi-squared test. Therefore S {\displaystyle S} is computationally related to the independence model used in that test. But since CA is not an inferential method the term independence model is inappropriate here. === Orthogonal components === The table S {\displaystyle S} is then decomposed by a singular value decomposition as S = U Σ V ∗ {\displaystyle S=U\Sigma V^{}\,} where U {\displaystyle U} and V {\displaystyle V} are the left and right singular vectors of S {\displaystyle S} and Σ {\displaystyle \Sigma } is a square diagonal matrix with the singular values σ i {\displaystyle \sigma _{i}} of S {\displaystyle S} on the diagonal. Σ {\displaystyle \Sigma } is of dimension p ≤ ( min ( m , n ) − 1 ) {\displaystyle p\leq (\min(m,n)-1)} hence U {\displaystyle U} is of dimension m×p and V {\displaystyle V} is of n×p. As orthonormal vectors U {\displaystyle U} and V {\displaystyle V} fulfill U ∗ U = V ∗ V = I {\displaystyle U^{}U=V^{}V=I} . In other words, the multivariate information that is contained in C {\displaystyle C} as well as in S {\displaystyle S} is now distributed across two (coordinate) matrices U {\displaystyle U} and V {\displaystyle V} and a diagonal (scaling) matrix Σ {\displaystyle \Sigma } . The vector space defined by them has as number of dimensions p, that is the smaller of the two values, number of rows and number of columns, minus 1. === Inertia === While a principal component analysis may be said to decompose the (co)variance, and hence its measure of success is the amount of (co-)variance covered by the first few PCA axes - measured in eigenvalue -, a CA works with a weighted (co-)variance which is called inertia. The sum of the squared singular values is the total inertia I {\displaystyle \mathrm {I} } of the data table, computed as I = ∑ i = 1 p σ i 2 . {\displaystyle \mathrm {I} =\sum _{i=1}^{p}\sigma _{i}^{2}.} The total inertia I {\displaystyle \mathrm {I} } of the data table can also computed directly from S {\displaystyle S} as I = ∑ i = 1 n ∑ j = 1 m s i j 2 . {\displaystyle \mathrm {I} =\sum _{i=1}^{n}\sum _{j=1}^{m}s_{ij}^{2}.} The amount of inertia covered by the i-th set of singular vectors is ι i {\displaystyle \iota _{i}} , the principal inertia. The higher the portion of inertia covered by the first few singular vectors i.e. the larger the sum of the principal inertiae in comparison to the total inertia, the more successful a CA is. Therefore, all principal inertia values are expressed as portion ϵ i {\displaystyle \epsilon _{i}} of the total inertia ϵ i = σ i 2 / ∑ i = 1 p σ i 2 {\displaystyle \epsilon _{i}=\sigma _{i}^{2}/\sum _{i=1}^{p}\sigma _{i}^{2}} and are presented in the form of a scree plot. In fact a scree plot is just a bar plot of all principal inertia portions ϵ i {\displaystyle \epsilon _{i}} . === Coordinates === To transform the singular vectors to coordinates which preserve the chi-square distances between rows or columns an additional weighting step is necessary. The resulting coordinates are called principal coordinates in CA text books. If principal coordinates are used for
Dynamic Bayesian network
A dynamic Bayesian network (DBN) is a Bayesian network (BN) which relates variables to each other over adjacent time steps. == History == A dynamic Bayesian network (DBN) is often called a "two-timeslice" BN (2TBN) because it says that at any point in time T, the value of a variable can be calculated from the internal regressors and the immediate prior value (time T-1). DBNs were developed by Paul Dagum in the early 1990s at Stanford University's Section on Medical Informatics. Dagum developed DBNs to unify and extend traditional linear state-space models such as Kalman filters, linear and normal forecasting models such as ARMA and simple dependency models such as hidden Markov models into a general probabilistic representation and inference mechanism for arbitrary nonlinear and non-normal time-dependent domains. Today, DBNs are common in robotics, and have shown potential for a wide range of data mining applications. For example, they have been used in speech recognition, digital forensics, protein sequencing, and bioinformatics. DBN is a generalization of hidden Markov models and Kalman filters. DBNs are conceptually related to probabilistic Boolean networks and can, similarly, be used to model dynamical systems at steady-state.
CloudSim
CloudSim is a framework for modeling and simulation of cloud computing infrastructures and services. Originally built primarily at the Cloud Computing and Distributed Systems (CLOUDS) Laboratory, the University of Melbourne, Australia, CloudSim has become one of the most popular open source cloud simulators in the research and academia. CloudSim is completely written in Java. The latest version of CloudSim is CloudSim v6.0.0-beta on GitHub. Cloudsim is suitable for implementing simulations scenarios based on Infrastructure as a service as well as with latest version Platform as a service, so get started here == CloudSim extensions == Initially developed as a stand-alone cloud simulator, CloudSim has further been extended by independent researchers. GPUCloudSim is an enhanced CloudSim tool for modeling GPU-based cloud infrastructures and data centers. It offers simulations for multi-GPU setups, customizable GPU policies, GPU remoting, etc. It also examines performance impacts and interactions within virtualized GPU environments. CloudSim Plus is a totally re-engineered CloudSim fork providing general-purpose cloud computing simulation and exclusive features such as: multi-cloud simulations, vertical and horizontal VM scaling, host fault injection and recovery, joint power- and network-aware simulations and more. Though CloudSim itself does not have a graphical user interface, extensions such as CloudReports offer a GUI for CloudSim simulations. CloudSimEx extends CloudSim by adding MapReduce simulation capabilities and parallel simulations. Cloud2Sim extends CloudSim to execute on multiple distributed servers, by leveraging Hazelcast distributed execution framework. RECAP DES extends the CloudSim Plus framework to model synchronous hierarchical architectures (such as ElasticSearch). ThermoSim extends CloudSim toolkit by incorporating thermal characteristics, and uses Deep learning-based temperature predictor for cloud nodes.
Inverted pendulum
An inverted pendulum is a pendulum that has its center of mass above its pivot point. It is unstable and falls over without additional help. It can be suspended stably in this inverted position by using a control system to monitor the angle of the pole and move the pivot point horizontally back under the center of mass when it starts to fall over, keeping it balanced. The inverted pendulum is a classic problem in dynamics and control theory and is used as a benchmark for testing control strategies. It is often implemented with the pivot point mounted on a cart that can move horizontally under control of an electronic servo system as shown in the photo; this is called a cart and pole apparatus. Most applications limit the pendulum to 1 degree of freedom by affixing the pole to an axis of rotation. Whereas a normal pendulum is stable when hanging downward, an inverted pendulum is inherently unstable, and must be actively balanced in order to remain upright; this can be done either by applying a torque at the pivot point, by moving the pivot point horizontally as part of a feedback system, changing the rate of rotation of a mass mounted on the pendulum on an axis parallel to the pivot axis and thereby generating a net torque on the pendulum, or by oscillating the pivot point vertically. A simple demonstration of moving the pivot point in a feedback system is achieved by balancing an upturned broomstick on the end of one's finger. A second type of inverted pendulum is a tiltmeter for tall structures, which consists of a wire anchored to the bottom of the foundation and attached to a float in a pool of oil at the top of the structure that has devices for measuring movement of the neutral position of the float away from its original position. == Overview == A pendulum with its bob hanging directly below the support pivot is at a stable equilibrium point, where it remains motionless because there is no torque on the pendulum. If displaced from this position, it experiences a restoring torque that returns it toward the equilibrium position. A pendulum with its bob in an inverted position, supported on a rigid rod directly above the pivot, 180° from its stable equilibrium position, is at an unstable equilibrium point. At this point again there is no torque on the pendulum, but the slightest displacement away from this position causes a gravitation torque on the pendulum that accelerates it away from equilibrium, causing it to fall over. In order to stabilize a pendulum in this inverted position, a feedback control system can be used, which monitors the pendulum's angle and moves the position of the pivot point sideways when the pendulum starts to fall over, to keep it balanced. The inverted pendulum is a classic problem in dynamics and control theory and is widely used as a benchmark for testing control algorithms (PID controllers, state-space representation, neural networks, fuzzy control, genetic algorithms, etc.). Variations on this problem include multiple links, allowing the motion of the cart to be commanded while maintaining the pendulum, and balancing the cart-pendulum system on a see-saw. The inverted pendulum is related to rocket or missile guidance, where the center of gravity is located behind the center of drag causing aerodynamic instability. The understanding of a similar problem can be shown by simple robotics in the form of a balancing cart. Balancing an upturned broomstick on the end of one's finger is a simple demonstration, and the problem is solved by self-balancing personal transporters such as the Segway PT, the self-balancing hoverboard and the self-balancing unicycle. Another way that an inverted pendulum may be stabilized, without any feedback or control mechanism, is by oscillating the pivot rapidly up and down. This is called Kapitza's pendulum. If the oscillation is sufficiently strong (in terms of its acceleration and amplitude) then the inverted pendulum can recover from perturbations in a strikingly counterintuitive manner. If the driving point moves in simple harmonic motion, the pendulum's motion is described by the Mathieu equation. == Equations of motion == The equations of motion of inverted pendulums are dependent on what constraints are placed on the motion of the pendulum. Inverted pendulums can be created in various configurations resulting in a number of Equations of Motion describing the behavior of the pendulum. === Stationary pivot point === In a configuration where the pivot point of the pendulum is fixed in space, the equation of motion is similar to that for an uninverted pendulum. The equation of motion below assumes no friction or any other resistance to movement, a rigid massless rod, and the restriction to 2-dimensional movement. θ ¨ − g ℓ sin θ = 0 {\displaystyle {\ddot {\theta }}-{g \over \ell }\sin \theta =0} Where θ ¨ {\displaystyle {\ddot {\theta }}} is the angular acceleration of the pendulum, g {\displaystyle g} is the standard gravity on the surface of the Earth, ℓ {\displaystyle \ell } is the length of the pendulum, and θ {\displaystyle \theta } is the angular displacement measured from the equilibrium position. When θ ¨ {\displaystyle {\ddot {\theta }}} added to both sides, it has the same sign as the angular acceleration term: θ ¨ = g ℓ sin θ {\displaystyle {\ddot {\theta }}={g \over \ell }\sin \theta } Thus, the inverted pendulum accelerates away from the vertical unstable equilibrium in the direction initially displaced, and the acceleration is inversely proportional to the length. Tall pendulums fall more slowly than short ones. Derivation using torque and moment of inertia: The pendulum is assumed to consist of a point mass, of mass m {\displaystyle m} , affixed to the end of a massless rigid rod, of length ℓ {\displaystyle \ell } , attached to a pivot point at the end opposite the point mass. The net torque of the system must equal the moment of inertia times the angular acceleration: τ n e t = I θ ¨ {\displaystyle {\boldsymbol {\tau }}_{\mathrm {net} }=I{\ddot {\theta }}} The torque due to gravity providing the net torque: τ n e t = m g ℓ sin θ {\displaystyle {\boldsymbol {\tau }}_{\mathrm {net} }=mg\ell \sin \theta \,\!} Where θ {\displaystyle \theta \ } is the angle measured from the inverted equilibrium position. The resulting equation: I θ ¨ = m g ℓ sin θ {\displaystyle I{\ddot {\theta }}=mg\ell \sin \theta \,\!} The moment of inertia for a point mass: I = m R 2 {\displaystyle I=mR^{2}} In the case of the inverted pendulum the radius is the length of the rod, ℓ {\displaystyle \ell } . Substituting in I = m ℓ 2 {\displaystyle I=m\ell ^{2}} m ℓ 2 θ ¨ = m g ℓ sin θ {\displaystyle m\ell ^{2}{\ddot {\theta }}=mg\ell \sin \theta \,\!} Mass and ℓ 2 {\displaystyle \ell ^{2}} is divided from each side resulting in: θ ¨ = g ℓ sin θ {\displaystyle {\ddot {\theta }}={g \over \ell }\sin \theta } === Inverted pendulum on a cart === An inverted pendulum on a cart consists of a mass m {\displaystyle m} at the top of a pole of length ℓ {\displaystyle \ell } pivoted on a horizontally moving base as shown in the adjacent image. The cart is restricted to linear motion and is subject to forces resulting in or hindering motion. === Essentials of stabilization === The essentials of stabilizing the inverted pendulum can be summarized qualitatively in three steps. 1. If the tilt angle θ {\displaystyle \theta } is to the right, the cart must accelerate to the right and vice versa. 2. The position of the cart x {\displaystyle x} relative to track center is stabilized by slightly modulating the null angle (the angle error that the control system tries to null) by the position of the cart, that is, null angle = θ + k x {\displaystyle =\theta +kx} where k {\displaystyle k} is small. This makes the pole want to lean slightly toward track center and stabilize at track center where the tilt angle is exactly vertical. Any offset in the tilt sensor or track slope that would otherwise cause instability translates into a stable position offset. A further added offset gives position control. 3. A normal pendulum subject to a moving pivot point such as a load lifted by a crane, has a peaked response at the pendulum radian frequency of ω p = g / ℓ {\displaystyle \omega _{p}={\sqrt {g/\ell }}} . To prevent uncontrolled swinging, the frequency spectrum of the pivot motion should be suppressed near ω p {\displaystyle \omega _{p}} . The inverted pendulum requires the same suppression filter to achieve stability. As a consequence of the null angle modulation strategy, the position feedback is positive, that is, a sudden command to move right produces an initial cart motion to the left followed by a move right to rebalance the pendulum. The interaction of the pendulum instability and the positive position feedback instability to produce a stable system is a feature that makes the mathematical analysis an interesting and challenging problem. === From Lagrange's equations === The equations of motion c
